| Key Features | 10.1" IPS + Intel J4125 + 8GB + 128GB + WiFi 5 + 1000Mbps千兆网 + HDMI1.4 X 2+ USB3.0 X 4 |
| System Physical Standard Configuration: |
| Type | Details | Descriptions |
| Product Form | Form Factor | 10.1" pc+Tablet |
| Dimensions | 241.5*160.2*66.1mm |
| Weight | 0.8kg |
| LCD | Screen Size | 10.1" |
| Screen Resolution | 1920*1200 (IPS ) |
| TP | Touch Module | G+G 5 Multi-Touch |
| System Hardware Configuration: |
| Type | Details | Descriptions |
| CPU | Type | Intel Celeron J4125 |
| Speed | 2.0GHz ~ 2.70GHz |
| GPU | Type | Intel HD600 Graphics |
| Memory | Capacity | 8GB(Optional) LPDDR4 |
| Storage | eMMC | 128GB(Optional) |
| SSD | / |
| SATA 2.5“ HDD | / |
| Speaker | Built-in | Optional 8Ω/1W |
| Micphone | Built-in | / |
| G-sensor | Built-in | / |
| Network Connections: |
| Type | Details | Descriptions |
| WIFI | WIFI Module: Realtek 8723BS | WiFi 5.0 |
| Bluetooth | BT Module: Realtek 8723BS | Bluetooth 5.2 |
| Ethernet Network | RJ-45 | 1000Mbps Gigabit Lan |
| Interface Configuration: |
| Type | Details | Descriptions |
| USB Interface | USB3.0 | ×4pc |
| Type-C | Type-C 3.1 | ×1pc |
| SD / TF Card reader | TF Card reader | ×1pc (up to 128GB) |
| Audio Jack |
| 3.5mm headphone (Output only) |
| ×1pc |
| COM Port |
| DB9 (RS232) |
| ×2pc |
| HDMI | HDMI 1.4 | ×2pc |
| Button Switch: |
| Type | Details | Descriptions |
| Power | On/Off | ×1pc |
| Volume | Down/UP | / |
| CMOS Reset | Reset by Short Press | / |
| Main Accessories: |
| Type | Details | Descriptions |
| Power adapter | DC 12V/3A | ×1pc |
| User's Manual | User's Manual | ×1pc |
| Software Configuration: |
| Type | Details | Descriptions |
| Power on Function | By Power Button or Auto Power on | Optional |
| Wake up on Lan | Wake up on Lan by RJ45 | Support |
| PXE | Preboot Execution Environment | Support |
| Operating System | Windows 11 | Optional |
| Linux | Optional |
| Certification: |
| CE | CE | / |
| Other | Other | Optional |
