Key Features | IP67, 10.1" IPS + Z8350 + 4GB +64GB + WiFi 2.4G&5G Dual band + 1000Mbps + HDMI1.4 + RS-232(DB9)+ USB3.0 |
System Physical Standard Configuration: |
Type | Details | Descriptions |
Product Form | Form Factor | IP67 Rugged Tablet PC |
Dimensions | 280×184×26.5mm |
Weight | 1.2KG |
LCD | Screen Size | 10.1" |
Screen Resolution | 1200×1920 (IPS+FHD+600ANSI) (Standrd) |
800×1280 (IPS+HD+300ANSI) (Optional, For MOQ order) |
TP | Touch Module | G+G Multi-Touch |
Battery | Type | Rechargeable lithium polymer |
Capacity | 16000mAh/3.7V |
Working Time | Over 8 hours (FHD local video display) |
System Hardware Configuration: |
Type | Details | Descriptions |
CPU | Type | Intel Cherry Trail x5-Z8350 Quad-Core |
Speed | 1.44GHz ~ 1.92GHz |
GPU | Type | Intel HD Graphics Gen8 |
Memory | Capacity | 4GB |
Storage | eMMC | 64GB |
SSD | / |
SATA 2.5“ HDD | / |
Camera | Front | 2M |
Rear | 5M |
Speaker | Built-in | 8Ω/1W with water proof |
Micphone | Built-in | Yes |
G-sensor | Built-in | Yes |
Network Connections: |
Type | Details | Descriptions |
WIFI | WIFI Module: Broadcom AP6255/AP6256 | WIFI 802.11ac/b/g/n 2.4G&5Ghz Dual-band |
Bluetooth | BT Module: Broadcom AP6255/AP6256 | Bluetooth4.0 |
3G/4G LTE | standard | standard |
QR code Scanners | Optional | Optional |
NFC | Optional | Optional |
GPS | BD2/GPS | standard |
Fingerprinter | Capacitive fingerprint sensor | Optional |
Ethernet Network | RJ-45 | 1000Mbps Gigabit Lan |
Interface Configuration: |
Type | Details | Descriptions |
USB Interface | USB3.0 | ×1pc |
USB2.0 | ×2pcs (USB2.0 TypeA×1 + Micro USB2.0×1) |
SD / TF Card reader | TF Card reader | ×1pc (up to 128GB) |
SIM Card Slot | SIM Slot for 3G/4G LTE | Optional |
Audio Jack | 3.5mm standard | ×1pc |
HDMI | Micro HDMI 1.4 | ×1pc |
Video output through HDMI | Up to 4K |
COM Port | DB9 (RS232) | ×1pc (External small PCBA) |
Button Switch: |
Type | Details | Descriptions |
Power | On/Off | ×1pc |
Volume | Down/UP | ×1pc |
CMOS Reset | Reset by Short Press | / |
Main Accessories: |
Type | Details | Descriptions |
Power adapter | DC 5V/3A | ×1pc |
User's Manual | User's Manual | ×1pc |
Handle Straps | Optional | Optional |
Extension Docking | USB2.0×1pc ; DC IN × 1pc | Optional |
Software Configuration: |
Type | Details | Descriptions |
Wake up on Lan | Wake up on Lan by RJ45 | / |
PXE | Preboot Execution Environment | / |
Operating System | Windows 11 | Optional |
Linux | Test by end user |
Environment: |
Temperature | Operation Temperature | -10oC ~ 55oC (1080p or 4K local video display) |
Storage Temperature | -20oC ~ 70oC (Restore to Operation Temperature 2hr before use) |
Humidity | Oprating Humidity | 35% ~ 80% relative humidity, Non-condensing |
Storage Humidity | 20% ~ 93% relative humidity, Non-condensing |
Certification: |
IP67 | IP67 Certification | Yes |
Other | Other | Optional |
